Technical Guidance:

Contact with UNICEF Supply Division, HTC, Cold Chain Unit for technical
questions. CPHHQ-SD-Cold Chain Unit

General Description

Ultra-low temperature Freezer

Model: DW-86L578J

Cabinet Type: Upright

Capacity: 578L

Volume Category: ≥ 300 <600L
Storage temperature: up to-86°C

Adjustable cabinet temperature set point -40°C to -86°C

Power requirement: 220-240V/50Hz

Operating ambient temperature: +10 °C - +32°C (Temperate zone)

Manufacturer: Qingdao Haier Biomedical Co., Ltd, China

Technical Specifications

Temperature Control

Microprocessor controlled via keypad. LED temperature display, Multiple
alarm functions: high temperature alarm, low temperature alarm, sensor
fault alarm, power failure alarm, low battery power alarm, hot
condenser, open door alarm and high ambient temperature alert. Sound and
light alarm mode, attachable to remote alarm interface. USB for data
download.

Refrigeration System

Cascaded, Two Hermetic reciprocating compressors

Shelving and doors

3 X Stainless steel shelves

4 X Insulated inner doors

Wheels: Fitted with integrated Casters with double locks.

Voltage regulator

Supplied with an automatic Standalone voltage stabilizer, extended type,
SANKE, Model: SVR-3000VA, 3KVA, Input: 100 -260V/50-60Hz, Output: 220V
±10%. Microprocessor controlled spike and surge protection, and
protection against disturbances.

Cryo gloves: Small size 2 pairs, Medium size 2 pairs and Large
size 2 pairs

Ice scrapers: Big ice scrapers 2 EA and Ice clearing brushes 2EA

Warranty

Covered by a two-year replacement warranty in the event of any component
failure arising from defective design, materials or Workmanship.

Manuals

User and maintenance instructions in one of the languages upon request:
Arabic, Mandarin Chinese, English, French, Russian and Spanish. The
instructions to be written for users and repair technicians and are to
cover the following topics: installation procedures; routine maintenance
tasks; diagnostic and repair procedures.

Shipping Information:

Packaging and labelling;

Estimated shipping weight: 340 kg

Estimated shipping volume: 2.2m³

Temperature for storage and shipping: -30°C to +70°C

NOTES:

When placing order UNICEF CO or partners should contact cold chain
unit/HTC for technical and commercial guidance. It is also important to
notify the voltage & frequency to ensure correct choice of refrigerator
and voltage regulator.
