General:

Berlinger Freeze tag is an irreversible temperature indicator that will
be packed with freezer sensitive vaccine during transport or during
storage in fixed locations, used to warn of exposure to temperature
below -0.5°C.

WHO PQS number: E006/007

Specification reference: E06/IN03.1

Product verification protocol: E06/IN03.VP.1

Technical specifications:

Operating temperature: -20°C to +55°C

Alarm: Visual, display shows either a tick for OK or a cross for Alarm
display (if the indicator is exposed to a temperature below - 0.5 °C for
more than 60 min)

Display medium: LCD

User interface: LCD

Accuracy: +/- 0.5 °C

Battery type: Non-replaceable Lithium coin cell battery

Battery shelf life: 60 months

Activated life: Device always active (60 months battery life)

IP rating: IP67

Packaging and labelling:

Cardboard box:1 Box = 500 units - Minimum order 500 Units

Volume per box: 0.03 m³

Weight per box: 7.5 Kg

Unit Weight: 0.014 Kg

Unit Dimensions 4.9 x 3 x 1.1 cm

Packaging when palletized:

Number of cartons per pallet: 18

Number of units per pallet: 9000

Dimensions of packed pallet (LxWxH): 120 x 80 x 99 cm

Net weight per packed pallet (Kgs): 135

Net volume per packed pallet (CBM): 0.529 m3

Warranty:

The product is to be covered by a two year replacement warranty in the
event of any component failure not caused by mechanical damage.
