Technical Guidance: Contact UNICEF Supply Division, HTC, Cold
Chain Unit for technical questions. CPHHQ-SD-Cold Chain Unit:
sd.coldchain@unicef.org

General Description:

Mains Powered, Ice-lined Combined Refrigerator & Waterpack Freezer.

Model: Haier HBCD-90

PQS ref. E003/097

Technical specifications:

Net vaccine storage volume: 30L

Water-pack freezing capacity per 24 hours: 4 kg

Water-pack storage capacity: 16 kg

Power requirement: 220-240V 50Hz

Refrigerant type: R600a

Ambient operating temperature: Min. +5°C, Max. +43°C

Freeze Protection: Grade A

Vaccine storage volume category: ≥30, <60LSupplied with:

1.Temperature Monitoring Device- 30 day electronic refrigerator
temperature logger:

Haier HETL-01, E006/042 attached to internal refrigerator basket

OR

Upon request: Either Berlinger Fridge-Tag 2E, E006/040 with an internal
sensor attached to internal refrigerator basket or Fridge-Tag 2E with
external sensor, E006/040 shall be supplied.

2.Voltage regulator: A standalone voltage stabilizer (HVS-1000) is
provided. The voltage stabilizer is in compliance with E007/VS01.3 for
bundled voltage regulators.

Upon request extended type Stand-alone, Sollatek, Model SVS04E-22, 230V
50/60Hz nominal output, 100-290V input voltage regulation range.

3.Schuko plug as a standard and 2 meters power lead.

4.Lid with lock, plus 2 keys and 4 baskets (2 denser wire baskets for
fridge part, 2 common baskets for freezer part).

Manuals:

User, installation, and maintenance documents that address all the five
aspects as outlined in the applicable WHO/PQS specification will be
supplied in English as a standard.

Shipping Information:

Packaging and labelling: Reinforced Carton and plywood pallet

Estimated shipping weight: 118 kg

Estimated shipping volume: 0.98 m³

Warranty:

The product is covered by a two-year replacement warranty in the event
of any component failure arising from defective design, materials or
workmanship.

NOTES:

1.UNICEF CO or partners should notify the voltage & frequency to
ensure correct choice of refrigerator and voltage regulator.

2.Manuals in other UN languages are available upon request.

3.A label, displaying vaccine storage advice & user instructions with
pictures is permanently mounted on cabinet. Label is in the UN languages
(Arabic, English, French, Mandarin Chinese, Russian or Spanish, or other
language be available on demand).

4.Maintenance tool kits are available on request. (For contents, see
supply web catalogue.)

5.One set of spare parts is recommended but not compulsory for every
10 units of ILRs.

6.Further information for comparable products, can be obtained from
CPHHQ-SD-Cold Chain Unit: sd.coldchain@unicef.org
